W321/341 Linux Managing Embedded Linux
3-2
System Version Information
To determine the hardware capability of your W321/341, and what kind of software functions are
supported, check the version numbers of your W321/341’s hardware, kernel, and user file system.
Contact Moxa to determine the hardware version. You will need the Production S/N (Serial number),
which is located on the W321/341’s bottom label.
To check the kernel version, type:
#kversion
192.168.3.127 - PuTTY
root@Moxa:~# kversion
W321-LX ersion 3.0.0
root@Moxa:~# kversion –a
W321-LX version 3.0 Build 13031118
NOTE
The kernel version number is for the factory default configuration. You may download the latest firmware
version from Moxa’s website and then upgrade the
W321/341’s hardware.
System Image Backup
Upgrading the Firmware
The W321/341’s bios, kernel, and root file system are combined into one firmware file, which can be
downloaded from Moxa’s website
www.moxa.com). The name of the file has the form w321-x.x.x.frm
or w341-x.x.x.frm, with “x.x.x” indicating the firmware version. To upgrade the firmware, download
the firmware file to a PC, and then transfer the file to the W321/341 using a console port or Telnet
console connection.
ATTENTION
Upgrading the firmware will erase all data on the Flash ROM
If you are using the ramdisk to store code for your applications, beware that updating the firmware will erase
all of the data on the Flash ROM. You should back up your application files and data before updating the
firmware.
Since different Flash disks have different sizes, it is a good idea to check the size of your Flash disk
before upgrading the firmware, or before using the disk to store your application and data files. Use the
#df –h command to list the size of each memory block and how much free space is available in each
block (see next page for commands)
