W321/341 Linux Getting Started
2-9
frequency
Countries apply their own
regulations to both the allowable
channels, allowed users and
maximum power levels within these
frequency ranges. Consult your
local authorities as these
regulations may be out of date as
they are subject to change at any
time. Most of the world will allow the
first thirteen channels in the
spectrum.
proto
{WPA}
List of acceptable protocols: WPA
key_mgmt
{ WPA-NONE }
List of acceptable key management
protocols: WPA-NONE
pairwise {CCMP} List of acceptable pairwise (unicast)
ciphers for WPA; one or more of:
CCMP (AES in Counter mode with
CBC-MAC, RFC 3610,
IEEE802.11i/D7.0), TKIP (Temporal
Key Integrity Protocol,
IEEE802.11i/D7.0), NONE
(deprecated). If you do not
configure, the default value is
"CCMP TKIP".
group
{CCMP, TKIP, WEP104, WEP40}
List of acceptable group (multicast)
ciphers for WPA; one or more of:
CCMP (AES in Counter mode with
CBC-MAC, RFC 3610,
IEEE802.11i/D7.0), TKIP (Temporal
Key Integrity Protocol,
IEEE802.11i/D7.0), WEP104 (WEP
with 104-bit key), EP40 (WEP with
40-bit key). If you do not configure,
the default value is "CCMP TKIP
WEP104 WEP40".
psk
{preshared key}
WPA preshared key used in
WPA-PSK mode. The key is
specified as 64 hex digits or as an
8-63 character ASCII passphrase.
mode # 0 = infrastructure (Managed) mode, i.e., associate
with an AP (default)
# 1 = IBSS (ad-hoc, peer-to-peer)
IEEE 802.11 operation mode
NOTE
Click on the following links for more information about wpa_supplicant.conf.
http://www.daemon-systems.org/man/wpa_supplicant.conf.5.html
http://linux.die.net/man/5/wpa_supplicant.conf
