W321/341 Linux Getting Started
2-11
root@Moxa:/home# wpa_cli -i wlan0 add_network
1
root@Moxa:/home# wpa_cli
-i wlan0 set_network 1 ssid '"MOXA-AP"'
OK
root@Moxa:/home# wpa_cli
-i wlan0 set_network 1 proto 'WPA WPA2 RSN'
OK
root@Moxa:/home# wpa_cli
-i wlan0 set_network 1 key_mgmt 'WPA-PSK'
OK
root@Moxa:/home# wpa_cli
-i wlan0 set_network 1 pairwise 'TKIP CCMP'
OK
root@Moxa:/home# wpa_cli
-i wlan0 set_network 1 group 'TKIP CCMP'
OK
root@Moxa:/home# wpa_cli
-i wlan0 set_network 1 psk '"01234567890"'
'SET_NETWORK 1 psk "01234567890"' command timed out.
root@Moxa:/home# wpa_c
li -i wlan0 enable_network 1
OK
root@Moxa:/home# wpa_cli
-iwlan0 select_network 1
OK
root@Moxa:/home# wpa_cli
-i wlan0 save_config
OK
The following wpa_cli commands are available:
Command
Function
wpa_cli -i wlan0 status
get current WEP/WPA/EAPOL/EAP status
wpa_cli -i wlan0 help
show this usage help
wpa_cli -i wlan0 terminate
terminate wpa_supplicant
wpa_cli -i wlan0 interface
show interfaces/select interface
wpa_cli -i wlan0 list_networks
list configured networks in wpa_supplicant.conf
wpa_cli -i wlan0 select_network
Set network variables. Network id can be received from
the LIST_NETWORKS command output. This command
uses the same variables and data formats as the
configuration file.
wpa_cli -i wlan0 enable_network
Enable a network. Network id can be received from the
LIST_NETWORKS command output.
wpa_cli -i wlan0 disable_network
Disable a network. Network id can be received from the
LIST_NETWORKS command output. Special network id all
can be used to disable all networks.
wpa_cli -i wlan0 remove_network
Remove a network. Network id can be received from the
LIST_NETWORKS command output. Special network id all
can be used to remove all networks.
wpa_cli -i wlan0 reconfigure
Force wpa_supplicant to re-read its configuration file
wpa_cli -i wlan0 save_config
Save the current configuration. (Replace original
/etc/Wireless/wpa_supplicant.conf file)
wpa_cli -i wlan0 scan
wpa_cli -i wlan0 scan_results
Scan available networks
Get scanning results
SD Slot and USB for Storage Expansion
The W321/341 provides an SD slot for storage expansion. Moxa provides an SD flash disk for plug & play
expansion that allows users to plug in a Secure Digital (SD) memory card compliant with the SD 1.0 standard
for up to 1 GB of additional memory space, or a Secure Digital High Capacity (SDHC) memory card compliant
with the SD 2.0 standard for up to 16 GB of additional memory space. The following steps show you how to
install SD card into the W321/341.
W321
The SD slot is located on the right side of the W321 enclosure. To install an SD memory card, you must first
remove the SD slot’s protective cover to access the slot, and then plug the SD card directly into the slot.
