Loewe Spheros R 42 [31/42] What to do when
![Loewe Spheros R 42 [31/42] What to do when](/views2/1020449/page31/bg1f.png)
31
Remedy
a) Follow the instructions in the TV menu -
Connections again and select the
appropriate decoder programs.
b) Follow the instructions in the TV menu -
Connections again and select the right
sound source (decoder, TV or Autom.), see
instructions of the decoder.
Change the setting to "TV".
Set your menu language:
1. Switch off picture-in-picture (PIP) and switch
off all on-screen displays (END button)
2. Call the TV menu (MENU button)
3. Select the last menu item and press OK
4. Select the last menu item on the last page
and press the OK button
5. Now select the right language and....
6. ... confirm with OK.
a) Log in the Digital Link Plus VCR under
"Connections" and connect according to
the diagram.
b) Change the Euro-AV cable
c) Reinstate the original state (ex-factory) of
the VCR (see operating instructions of the
VCR)
d) Sort the terrestrial and cable stations so
that they are between 1 and 99.
Set the right character set: Teletext menu -
Settings - Character set - Standard or the
appropriate character set.
Possible cause
a) The signal is not decoded because the
correct decoder programs have not been
selected in the TV menu - Connections
b) The sound is missing in decoder mode
because the wrong decoder sound is
allocated in the TV menu - Connections
The item "Sound from..." in the Sound menu
under "Sound" is not set to "TV"
The wrong menu language has been set.
a) The VCR has not been logged in as a Digital
Link Plus device or has been connected to
the wrong socket
b) The Euro-AV cable is not fully wired (Pin 10
not wired)
c) Some video recorders can only take over the
stations from the TV in initial installation
d) All or some terrestrial or cable stations are
stored at station slots ≥ 99
The wrong character set is set in the teletext
menu
Problem
Connection of a decoder does not work or does
not work properly
No sound through the TV loudspeakers
All menus appear in the wrong language
Digital Link Plus does not work
Various characters are displayed incorrectly in
teletext
What to do when ...
31936_021_Spheros42HDR+_GB 18.10.2004, 10:18 Uhr31
