Appendix
241
KN2132VA / KN4132VA
Function KN2132VA KN4132VA
Computer
Connections
Direct 32
Max 512
Port Selection Pushbutton / GUI / Hotkey
Connectors Console
Port
Keyboard 1 x USB Type A Female (Black)
Video 1 x DVI-D Female (White)
1 x HDB-15 (Blue)
Mouse 1 x USB Type A Female (Black)
Audio 2 x Audio Jack (Female)
LUC Port 1 x Mini-USB Female (Black)
Console
Ext.
1 x RJ-45 Female (Black)
KVM Port 32 x RJ-45 Female (Black)
Power 2 x IEC 60320/C14
LAN 2 x RJ-45 Female (Black)
PON 1 x RJ-45 Female (Black)
Modem 1 x RJ-45 Female (Black)
USB
(Console/Virtual
Media)
3 x USB Type A Female (Black)
Switches Reset 1 x Semi-recessed Pushbutton
Power 2 x Rocker Switch
Port Selection 2 x Pushbutton
LEDs On Line 32 (Green)
Selected 32 (Orange)
Power 2 (Blue)
Link
10/100/1000 Mbps
2 (Red / Orange / Green)
Emulation Keyboard / Mouse PS/2 / USB (PC, Mac, Sun) / Serial
Video 1920 x 1200 @ 60Hz
Scan Interval 1–255 secs
I/P Rating 100–240VAC; 50–60Hz; 1.0A
Power
Consumption
Single Power 110V/43.2W; 220V/42.0W 110V/57.8W; 220V/56.7W
Dual Power 110V/22.0W; 220V/21.5W 110V/29.3W; 220V/28.9W
