KA7140 Pin Assignments

Pin assignments for the KA7140 Adapter are given in the table, below:

Pin Assignment

1 DCD

DB9 Female

2RXD

3TXD

4DTR

5GND

6DSR

7RTS

8CTS

9N/A
