KVM over IP Switch User Manual
vi
Package Contents
The KVM over IP switch package consists of:
1 KN2116VA / KN4116VA / KN2132VA / KN4132VA / KN8132V /
KN4164V / KN8164V Switch
2Power Cords
1 Mounting Kit
2 Lok-U-Plugs
1 Lok-U-Plug Installation Tool
2 SA0142 Serial Adapters
1 Foot Pad Set (4 pcs.)
1 User Instructions*
Check to make sure that all of the components are present and in good order.
If anything is missing, or was damaged in shipping, contact your dealer.
Read this manual thoroughly and follow the installation and operation
procedures carefully to prevent any damage to the switch or to any other
devices on the installation.
* Features may have been added since this manual was published. Please visit
our website to download the most up to date version of the manual.
Copyright © 2016 ATEN® International Co., Ltd.
Manual Date: 2016-05-06
Altusen and the Altusen logo are registered trademarks of ATEN International Co., Ltd. All rights reserved.
All other brand names and trademarks are the registered property of their respective owners.
