Aten KN8164V [51/307] Two stage installation diagram

Chapter 2. Hardware Setup

the First Stage switch can be powered on. After all the switches are

powered on, the servers can be powered on.

Two Stage Installation Diagram

Note: The diagram above shows an installation with the KN8132V.

Cascading other KN8 Series switches is same as the KN8132V and only

differs in that it provides additional KVM ports.
