Aten KN8164V [47/307] Single stage installation diagram

Chapter 2. Hardware Setup

Single Stage Installation Diagram

Note: The diagram above shows an installation with the KN8132V. Installing

other KN8 Series switches is same as the KN8132V and only differs in

that it provides additional KVM ports.

PN0108
