Chapter 1. Introduction
15
No. Component Description
1 Grounding
Terminal
The wire used to ground the unit connects here.
2 Power Switch These standard slide switches power the unit on and off.
3 Secondary LAN
Port
The cable that connects the unit to the backup network
interface (10/100/1000 Mbps) plugs in here.
4 PON Port This connector is provided for a Power over the Net™
(PON) unit which allows servers attached to the KVM over
IP switch to be booted remotely over the net.
See Single Stage Installation, page 27, step 6 for
installation details. Contact your dealer for more information
regarding PON units.
5 KVM Ports The Cat 5e cables that link the unit to the KVM Adapter
Cables (which connect to the servers), plug in here.
6 Power Sockets The power cable(s) plugs in here. The left power socket
corresponds to the left power switch, and the right power
socket corresponds to the right power switch.
7 Primary LAN
Port
The cable that connects the unit to the primary network
interface (10/100/1000 Mbps) plugs in here.
8 Modem Port For dial in connection should the unit be unavailable over
the network. See Single Stage Installation, page 27, step 7
for installation details.
9 Remote
Console Port
This port is reserved and will be available for use with future
upgrades as a remote console port.
10 Local Console
Port(s)
The unit can be accessed via a local console as well as over
the Net. The local console devices (USB keyboard, USB
mouse, DVI-D or VGA monitor) plug in here.
