10
JP7: CPU frequency select jumper
Use this jumper to force a CPU that has a 100 MHz frontside
bus (FSB) to run at a 133 MHz FSB speed.
Function Jumper Setting
Normal operation Short pins 1-2
Force a 100 MHz FSB to
run at 133 MHz FSB
Short pins 2-3
JP7
1 2 3
Note: The CPU speed is determined by the CPU Host/PCI Clock
speed multiplied by the CPU Clock Ratio. Refer to the Frequency
Control Option in Chapter 3 for more information.
Forcing the CPU to run at a higher clock speed then it was rated
for is called overclocking and is not recommended.
JP500: Set ROM voltage jumper
This jumper is used to select the voltage for the onboard ROM.
DO NOT make any adjustments to this jumper!
JP501: Set ROM memory size jumper
This jumper is used to select the memory size for the onboard ROM.
DO NOT make any adjustments to this jumper!
Important! Do not make any changes to JP500 or JP501. These
jumpers are set at the factory.
