Advanced Chipset Features Option

This option displays a table of items that define critical timing pa-

rameters of the mainboard components including the memory,

and the system logic. Generally, you should leave the items on

this page at their default values unless you are very familiar with

the technical specifications of your system hardware. If you

change the values incorrectly, you may introduce fatal errors or

recurring instability into your system.

Advanced Chipset Features

Item Help

Bank 0/1 DRAM Timing SDRAM 8/10ns

Bank 2/3 DRAM Timing SDRAM 8/10ns

Bank 4/5 DRAM Timing SDRAM 8/10ns

SDRAM Cycle Length 3

DRAM Clock Host CLK

Memory Hole Disabled

P2C/C2P Concurrency Enabled

Fast R-W Turn Around Disabled

System BIOS Cacheable Enabled

Video RAM Cacheable Enabled

AGP Aperture Size 64M

AGP-4X Mode Enabled

AGP Driving Control Auto

x AGP Driving Value DA

AGP Fast Write Disabled

OnChip USB Enabled

USB Keyboard Support Disabled

OnChip Sound Auto

Menu Level

↑ ↓ → ← : Move Enter : Select +/-/PU/PD:Value: F10: Save ESC: Exit F1:General Help

F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults

Bank 0/1 2/3 4/5 DRAM Timing Default: 8/10 ns

The DRAM timing is controlled by the DRAM Timing Registers. The tim-

ings programmed into this register are dependent on the system design.

Slower rates may be required in certain system designs to support

loose layouts or slower memory.

SDRAM Cycle Length Default: 3

This item sets the timing and wait states for SDRAM memory. We rec-

ommend that you leave this item at the default value.
