ECS Elitegroup MB694A [61/81] Integrated peripherals option
![ECS Elitegroup MB694A [61/81] Integrated peripherals option](/views2/1212445/page61/bg3d.png)
55
Integrated Peripherals Option
This option displays a list of items that defines the operation of
some peripheral components on the system’s input/output ports.
CMOS Setup Utility – Copyright (C) 1984 – 2000 Award Software
Integrated Peripherals
Item Help
OnChip IDE Channel0 Enabled
OnChip IDE Channel1 Enabled
IDE Prefetch Mode Enabled
Primary Master PIO Auto
Primary Slave PIO Auto
Secondary Master PIO Auto
Secondary Slave PIO Auto
Primary Master UDMA Auto
Primary Slave UDMA Auto
Secondary Master UDMA Auto
Secondary Slave UDMA Auto
Init Display First PCI Slot
IDE HDD Block Mode Enabled
Onboard FDD Controller Enabled
Onboard Serial Port 1 Auto
Onboard Serial Port 2 Auto
UART 2 Mode Standard
x IR Function Duplex Half
x TX,RX inverting enable No, Yes
Menu Level
↑ ↓ → ← : Move Enter : Select +/-/PU/PD:Value: F10: Save ESC: Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
On-Chip IDE Channel 0/1 Default: Enabled
Use these items to enable or disable the PCI IDE channels that are in-
tegrated on the mainboard.
IDE Primary/Secondary Master/Slave PIO Default: Auto
Each IDE channel supports a master device and a slave device. These
four items let you assign which kind of PIO (Programmed Input/Output)
is used by IDE devices. You can choose Auto, to let the system auto
detect which PIO mode is best, or you can install a PIO mode from 0-4.
IDE Primary/Secondary Master/Slave UDMA Default: Auto
Each IDE channel supports a master device and a slave device. This
mainboard supports UltraDMA. UltraDMA technology provides faster
access to IDE devices.
If you install a device that supports UltraDMA, change the appropriate
item on this list to Auto. You may have to install the UltraDMA driver
supplied with this mainboard in order to use an UltraDMA device.
