Soft-Off by PWRBTN Default: Instant-Off
Under ACPI (Advanced Configuration and Power management Inter-
face) you can create a software power down. In a software power down,
the system can be resumed by Wake Up Alarms. This item lets you in-
stall a software power down that is controlled by the normal power
button on your system. If the item is set to Instant-Off, then the power
button causes a software power down. If the item is set to Delay 4 Sec.
then you have to hold the power button down for four seconds to cause
a software power down.
Keyboard Power On Default: Disabled
Enable this item to allow the system to be resumed from a software
powerdown or a power-saving mode by a keystroke on the keyboard.
Wake Up Events
This item opens a submenu that enables you to set events that will re-
sume the system from a power saving mode. Select Wake Up Events
and press Enter to display the following menu:
CMOS Setup Utility – Copyright (C) 1984 – 2000 Award Software
Wake Up Events
Item Help
VGA OFF
LPT & COM LPT/COM
HDD & FDD ON
PCI Master OFF
PowerOn by PCI Card Enabled
Wake Up On LAN/Ring Disabled
RTC Alarm Resume Disabled
x Date (of Month) 0
x Resume Time (hh:mm:ss) 0 0 0
Primary INTR ON
IRQs Activity Monitoring Press Enter
Menu Level
↑ ↓ → ← : Move Enter : Select +/-/PU/PD:Value: F10: Save ESC: Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
VGA Default: Off
When set to On, the system power will resume the system from a
power saving mode if there is any VGA activity.
