48
CPU Internal Cache CPU Internal Cache Default: Enabled
All the processors that can be installed in this mainboard use internal
level 1 (L1) cache memory to improve performance. Leave this item at
the default value for better performance.
External Cache Default: Enabled
Most processors that can be installed in this system use external level 2
(L2) cache memory to improve performance.
CPU L2 Cache ECC Checking Default: Enabled
This item enables or disables ECC (Error Correction Code) error check-
ing on the CPU cache memory. We recommend that you leave this item
at the default value.
Processor Number Feature Default: Enabled
Some new processors are installed with a unique processor number.
This number may be used for verification in Internet transactions and e-
commerce. If you prefer not to use or distribute the unique processor
number, set this item to Disabled to suppress the processor number.
Quick Power On Self Test Default: Enabled
You can enable this item to shorten the power on testing (POST) and
have your system start up a little faster. You might like to enable this
item after you are confident that your system hardware is operating
smoothly.
1st/2nd/3rd Boot Device Default: Floppy/HDD-0/LS/ZIP
Use these three items to select the priority and order of the devices that
your system searches for an operating system at start-up time.
Boot Other Device Default: Enabled
If you enable this item, the system will search all other possible loca-
tions for an operating system if it fails to find one in the devices
specified under the first, second and third boot devices.
Swap Floppy Drive Default: Disabled
If you have two floppy diskette drives in your system, this item allows
you to swap the assigned drive letters so that drive A becomes drive B,
and drive B becomes drive A.
