50
performance. S.M.A.R.T. software resides on both the disk drive and
the host computer. The disk drive software monitors the internal per-
formance of the motors, media, heads, and electronics of the drive. The
host software monitors the overall reliability status of the drive. If a de-
vice failure is predicted, the host software, through the Client WORKS
S.M.A.R.T applet, warns the user of the impending condition and ad-
vises appropriate action to protect the data.
Report No FDD For WIN95 Default: Yes
If you are running a system with no floppy drive and using Windows 95,
select Yes for this item to ensure compatibility with the Windows 95
logo certification. Otherwise, select No.
Video BIOS Shadow Default: Enabled
When enabled, copies the VGA BIOS into system DRAM for better per-
formance.
C8000-CBFFF ~ DC000-DFFFF Shadow Default: Disabled
These categories determine whether option ROMs will be copied to
RAM. An example of such option ROM would be support of on-board
SCSI. The default value for each item is Disabled.
