65
PNP/PCI Configuration Option
This option displays a table of items that configures how PnP (Plug
and Play) and PCI expansion cards operate in your system. Both
the ISA and PCI buses on the Mainboard use system IRQs (Inter-
rupt ReQuests) and DMAs (Direct Memory Access). You must set
up the IRQ and DMA assignments correctly through the PnP/PCI
Configurations Setup utility; otherwise, the mainboard will not work
properly. Selecting PnP/PCI Configurations on the main program
screen displays this menu:
CMOS Setup Utility – Copyright (C) 1984 – 2000 Award Software
PnP/PCI Configurations
Item Help
PNP OS Installed No
Reset Configuration Data Disabled
Resources Controlled by Auto(ESCD)
x IRQ Resources Press Enter
x DMA Resources Press Enter
PCI/VGA Palette Snoop Disabled
Assign IRQ For VGA Enabled
Assign IRQ For USB Enabled
INT Pin 1 Assignment Auto
INT Pin 2 Assignment Auto
INT Pin 3 Assignment Auto
INT Pin 4 Assignment Auto
Menu Level
Select Yes if you are
using a Plug and Play
capable operating
system. Select No if
you need the BIOS to
configure non-boot
devices.
↑ ↓ → ← : Move Enter : Select +/-/PU/PD:Value: F10: Save ESC: Exit F1:General
Help F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
PNP OS Installed Default: No
Setting this option to Yes allows the PnP OS (instead of BIOS) to as-
sign the system resources such as IRQ and I/O address to the ISA PnP
device. The default setting is No.
Reset Configuration Data Default: Disabled
If you enable this item and restart the system, any Plug and Play con-
figuration data stored in the BIOS setup is cleared from memory. New
updated data is created.
