67
PCI Health Status Option
On mainboards that support hardware monitoring, this item lets
you monitor the parameters for critical voltages, critical tempera-
tures, and fan speeds. You cannot make any changes to these
fields. They are display only:
CMOS Setup Utility – Copyright (C) 1984 – 2000 Award Software
PC Health Status
Item Help
Shutdown Temperature Disabled
Current CPU Temp.
Current System Temp.
CPU Fan Speed
Power Fan Speed
Voltage Core
2.5V
3.3V
5.0V
12.0V
Menu Level
↑ ↓ → ← : Move Enter : Select +/-/PU/PD:Value: F10: Save ESC: Exit F1:General
Help F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
Shutdown Temperature
Enables you to set the maximum temperature the system can reach be-
fore powering down.
System Component Characteristics
These fields provide you with information about the systems current
operating status. You cannot make changes to these fields. The follow-
ing information is displayed:
• CPU temperature in degrees Fahrenheit and Celsius
• System temperature in degrees Fahrenheit and Celsius
• CPU fan speed (in RPMs)
• Power fan speed (in RPMs)
• Vcore (CPU core voltage)
• VCC SRAM (CPU L2 cache voltage)
• Vcc3 (onboard 3.3 volt)
• Power supply’s ± 5 volt
• Power supply’s ±12 volt
