External Connector Color Coding

To help identify the external connectors, many connectors now

use standard colors as shown in the table below.

Connector Color

Analog VGA Blue

Audio line in Light blue

Audio line out Lime

Digital monitor / flat panel White

IEEE 1394 Grey

Microphone Pink

MIDI/Game Gold

Parallel Burgundy

PS/2 compatible keyboard Purple

PS/2 compatible mouse Green

Serial Teal or Turquoise

Speaker out/subwoofer Orange

Right-to-left speaker Brown

USB Black

Video out Yellow

SCSI, network, telephone, modem None
