![Lainox REV101M [19/32] Operating at the rated heat output](/views2/1331519/page19/bg13.png)
19
90027260rev00
11 • OPERATING AT THE RATED HEAT OUTPUT
Checkthecombustion,CO (ppm) and CO2
(%)values,withanappropriateinstrument.
Starttheovenworking,withthedooropen,
and wait for approximately 5 minutes.
Position the flue gas collection probe in the
flue gas outlet pipe (chamber and boiler).
The CO
2 must be for:
Natural gas between 9% and 10.5%
L.P.G. between 9% and 13%
The CO must be no greater than 300 ppm
(measured).
I f these readings are outside the ranges,
proceed as stated in the technical manual.
For the conversion from natural gas to LPG,
or vice versa, proceed as described in the
technical manual.
Conversion: As mentioned above, every appliance is factory set to burn the type of gas
specified, it may become necessary nonetheless to convert the appliance from one type of gas
to another. Therefore, only personnel authorized by the company and belonging to the technical
service who have the corresponding technical handbook can do this work.
