1 • GENERAL REMINDERS
1.1 • The oven must be installed, commissioned
and maintained only by an authorized
service agent.
1.2 • Carefully read the directions given in this
manual; they contain important information
on safety during installation, operation and
maintenance.
Keep this manual in a safe place for future
consultation!
1.3 • This appliance must be put only to the
use for which it is specifically intended,
i.e. cooking foods; any other type of use is
improper and therefore dangerous.
1.4 • Havingremovedthepackingcheck that the
appliance is not damaged in any way.
If in doubt, proceed no further with
installation of the appliance and contact the
Customer Service or your dealer immediately.
1.5 • Packing materials are potentially dangerous
and must not be left where children can
play with them.
1.6 • Packing materials must be disposed of
in conformity with local regulations. This
normally means that the different materials
are sorted according to type and collected as
urban refuse.
1.7 • Before positioning and connecting the
appliance, check that the utilities (electrical
power, water and gas supplies) are as
indicated on the data plate.
1.8 • Example of a data plate:
1.9 • The positions of the inlet and drain
connections are clearly labelled. For further
details,seetheinstallationdiagramattached
to this manual.
1.10 • Intheeventofbreakdownorfaultyoperation,
switch off the oven immediately!
1.11 • During installation and/or maintenance
work it is recommended you wear gloves to
protect your hands.
1.12 • Safety sticker
• Maximum height for inserting containers with
liquids.
ATTENTION:toavoidscalding,donotuse
thecontainersfilledwithliquidorfoodwhich,
throughcookingbecomefluid,atlevels
higher than those which can be observed.
0085
2008
EN 203/A1 AC 230V 50Hz
IT
IPX 5
G 25 / m
3
/h
Qn 40 kW
Cat.
II 2H3+
NR XXXXXXXXXX
kPa
200 - 500
P mbar
20; 28-30/37
TOT 1 kW1 x 0.55 kW
G 20 / m
3
/h
G 30 3.16 Kg/h
Pmax / mbar Pmax / mbar
Pmin / mbar Pmin / mbar Pmin / mbar
A3 B13 B23
2008
3N AC 400V 50Hz
IPX 5
NR XXXXXXXXXX
kPa
200 - 500
TOT 8 kW1 x 0.25 kW
TYP. XXXXXXXX
TYP. XXXXXXXX
LOGO
LOGO
1600 mm (63 inch)
