TABLE 3: GENERAL WATER DATA
2 • TECHNICAL DATA
Model
Water
pressure
kPa
Softened
water
consumption
max. l/h
Water
connection
ELECTRIC
5 x GN 1/1 200 - 500 8 2 x R 3/4
(1)
7 x GN 1/1 200 - 500 16 2 x R 3/4
(1)
10 x GN 1/1 200 - 500 16 2 x R 3/4
(1)
GAS
5 x GN 1/1 200 - 500 8 2 x R 3/4
(1)
7 x GN 1/1 200 - 500 16 2 x R 3/4
(1)
10 x GN 1/1 200 - 500 16 2 x R 3/4
(1)
(1)
The ovens are equipped with two water inlets, one for non-softened cold water and the other for hot water (max. 50 C) or softened cold water.
