Lainox REV101M [9/32] Positioning
![Lainox REV101M [9/32] Positioning](/views2/1331519/page9/bg9.png)
9
90027260rev00
5.1 • To position the appliances, it is
recommended to use the mount offered
by the manufacturer; should you choose
otherwise, it is necessary to take account
of the weight of the appliance.
5.2
• Before manoeuvring the oven into the
selected position, attach the water inlet
hose (refer to headings describing the
water and drain connections).
5.3
• The distances from other appliances or
from adjacent walls that must be left to
allow access for servicing operations will
be found on the installation diagram for
the oven to connect. In the event of the
oven being installed directly against an
inflammable wall, suitable heat insulation
must be provided.
Current fire regulations should be
meticulously observed and respected. The
openings and slots in the outer casing of
the oven must not be blocked,as these
allow heat to escape from the compartment
housing the electrical components.
Keepstrictlytotheinstallationdiagrams.
5.4 • Once the appliance is installed, the
electrical power cable must be protected,
and never stretched or tugged.
5.5
• The appliance must be level: any difference
in level or sloping of the supporting surface
should be eliminated. Differences in level
or sloping negatively affect oven operation.
5.6 • Remove all packing materials and peel
away the protective plastic film from all
external and internal surfaces of the oven.
5 • POSITIONING
