Dell 7510 (7510-9822) [11/57] Installing the battery

Installing the battery

1. Slide the battery into its slot until it clicks into place.

2. Install the battery cover.

3. Follow the procedure in After working inside your computer

Removing the base cover

1. Follow the procedure in Before working inside your computer.

2. Remove the:

a. battery cover

b. battery

3. Perform the following steps as shown in the illustration:

a. Remove the screws that secure the base cover to the computer [1].

b. Slide and lift the base cover away from the computer [2].

Installing the base cover

1. Slide the base cover to align with the screw holes on the computer.

2. Tighten the screws to secure the base cover to the computer.

3. Install the:

a. battery

b. battery cover

4. Follow the procedure in After working inside your computer.

Removing the hard drive

1. Follow the procedure in Before working inside your computer.

2. Remove the:

a. battery cover

b. battery

3. Perform the following steps as shown in the illustration:

a. Remove the screws that secure the hard drive to the computer [1].
