Feature Specification
Connectors 4 SoDIMM Sockets
Capacity 4 GB, 8 GB, and 16 GB
Minimum Memory 8 GB
Maximum memory 64 GB
Table 19. Video
Feature Specification
Type MXM type-A add-in card
Data bus PCIE x16, Gen3
Video controller and memory:
• AMD FirePro W5170M, 2GB GDDR5
• Nvidia Quadro M1000M, 2GB GDDR5
• Nvidia Quadro M2000M, 4GB GDDR5
Table 20. Audio
Feature Specification
Integrated dual-channel High-Definition audio
Table 21. Communication
Feature Specification
Network adapter network interface card capable of 10/100/1000 Mb/s communication
Wireless
• internal wireless local area network (WLAN)
• internal wireless wide area network (WWAN)
• bluetooth wireless support
• High speed bluetooth 4.0
Table 22. Expansion Bus
Feature Specification
Bus Type PCI Express 1.0, 2.0 and 3.0, SATA 1.0A ,2.0 and 3.0, USB 2.0 and 3.0
Bus Width PCIe X16
BIOS Chip (NVRAM) 128 Mb (16 MB)
Table 23. Ports and Connectors
Feature Specification
Audio Universal audio jack connector
Network Adapter one RJ45 connector
USB C connector one (optional)
USB 3.0 four
Video 19-pin HDMI connector, Mini DisplayPort connector
Memory card reader SD 4.0
52
