GRAPHITE 58G784 [8/36] Environment protection

OPERATION / SETTINGS

SWITCHING ON / SWITCHING OFF

The mains voltage must match the voltage on the label of the

mixer.

The mixer is equipped with the switch, which protects against

accidental starting.

Switching on

• Press the switch lock button (4) located on the handle (g. B).

• Press the switch button (3).

Switching o

• Release pressure on the switch button (3).

2 GEAR SELECTOR SWITCH

Rotational speed can be changed with the use of two-position gear

switch (2) (g. C). Depending on the work being carried out, set the

gear switch to appropriate position.

• Position ‘1’ is for lower speed and greater torque.

• After switching to the right, to position ‘2’, the speed is greater and

the torque is lower.

• To restore lower speed set the switch back to the left position.

Never change the gear switch position under operation of the

mixer. It may damage the power tool. Turn the spindle slightly if

the switch position cannot be changed.

ROTATIONAL SPEED CONTROL

Wheel for rotational speed control (7) is located on the mixer handle

(g. D). Control range is from 1 to 6, the speed can be changed

depending on the user’s needs when working on either gear.

USE OF THE MIXER

• Ensure the power supply voltage is 230 V.

• Connect the power tool to the power supply network.

• During operation, always hold the mixer rmly (with both hands).

• Electronic controller allows for slow start of the mixing (no splash)

and slow stop.

• By turning the control wheel (7) you can increase or reduce

rotational speed of the spindle.

OPERATION AND MAINTENANCE

Unplug the power cord from the mains socket before commencing

any activities related to installation, adjustment, repair or

maintenance.

• Keep the mixer clean.

• When using the mixer always check that the ventilation holes are

not obstructed and no foreign body got between internal parts

of the power tool.

• Any maintenance or repairs should be carried out by an authorized

service workshop.

• During operation of the mixer, carbon brushes of the motor wear

out and they should be controlled and replaced regularly.

• Ball bearings of the mixer are greased for the whole time of mixer

operation.

REPLACEMENT OF CARBON BRUSHES

Replace immediately worn out (shorter than 5 mm), burnt or

cracked motor carbon brushes. Always replace both brushes at

a time.

Entrust replacement of carbon brushes only to a qualied person.

Only original parts should be used.

All faults should be repaired by service workshop authorized by the

manufacturer.

TECHNICAL PARAMETERS

RATED PARAMETERS

Electric Mixer

Parameter Value

Voltage 230 V AC

Frequency 50 Hz

Power consumption 1600 W

Spindle rotational

speed with no load

Gear I (low) 180 ÷ 460 rpm

Gear II (high) 300 ÷ 700 rpm

Mixer shaft connection M14, internal thread

Protection class II

Weight 5,86 kg

Year of production 2016

NOISE LEVEL AND VIBRATION PARAMETERS

Sound pressure Lp

= 87,4 dB(A) K = 3 dB(A)

Sound power Lw

= 98,4 dB(A) K = 3 dB(A)

Weighted value of vibration acceleration a

= 3,02 m/s

K = 1,5 m/s

ENVIRONMENT PROTECTION

Do not dispose of electrically powered products with household wastes,

they should be utilized in proper plants. Obtain information on wastes

utilization from your seller or local authorities. Used up electric and

electronic equipment contains substances active in natural environment.

Unrecycled equipment constitutes a potential risk for environment and

human health.

* Right to changes is reserved.

“Grupa Topex Spółka z ograniczoną odpowiedzialnością” Spółka komandytowa with seat in Warsaw at

ul. Pograniczna 2/4 (hereinafter Grupa Topex) informs, that all copyrights to this instruction (hereinafter

Instruction), including, but not limited to, text, photographies, schemes, drawings and layout of the

instruction, belong to Grupa Topex exclusively and are protected by laws accordingly to Copyright

and Related Rights Act of 4 February 2004 (ustawa o prawie autorskim i prawach pokrewnych, Dz. U.

2006 No 90 item 631 with later ammendments). Copying, processing, publishing, modications for

commercial purposes of the entire Instruction or its parts without written permission of Grupa Topex

are strictly forbidden and may cause civil and legal liability.
