8023 | V5.0_EN (11/2015)
Technical changes reserved
Trotec Laser GmbH
Page 26 of 61
1 Top lid
If the Top lid is opened, no data is processed. After closing the Top lid, the
device is not ready to process commands for 5 seconds. If the protection cover
is opened during operation, the motion system is stopped and laser source is
turned off.
Please note, that the laser tube is switched off immediately and consequently the result of
the engraving is incomplete. During processing of commands the protection cover must only
be opened after pressing the "Pause" button.
2 Service Access Panel
Only to be opened by trained technical service personnel.
3 Connection Socket for Rotary Attachment
Connector for the rotary attachment (option).
Supplies the rotary attachment with the required electric signals.
Always switch the machine off when you plug in and unplug the rotary
attachment.
4 Working Table
The work pieces to be processed are put onto the working table. To facilitate
orientation, a horizontal and a vertical ruler are located on the working table.
The table is ferromagnetic for easier fixation of work pieces.
