8023 | V5.0_EN (11/2015)
Technical changes reserved
Trotec Laser GmbH
Page 27 of 61
5 Front lid (opened in the shown picture)
If the front lid is opened, no data is processed. After closing the front lid, the
device is not ready to process commands for 5 seconds. If the front lid is
opened during operation, the motion system is stopped and laser source is
turned off.
Please note, that the laser tube is switched off immediately and consequently
the result of the engraving is incomplete. During processing of commands the
protection cover must only be opened after pressing the "Pause" button.
6 Vacuum table connection
Connection for vacuum on the table
7 Dust Protection (optional)
Avoids dust to get into the maintenance and service panel area.
8 Keypad
The Keypad contains multiple buttons and displays for controlling the device.
See section 4.4 Keypad for further information.
9 X axis
The motion system is the part that performs the mechanical movements in X
direction (horizontal) (Focusing head movement) and Y direction (vertical). The
X axis is visible in the working area.
10 Maintenance Panel
Has to be opened with a 10mm Allen key to maintain optics.
