8023 | V5.0_EN (11/2015)

Technical changes reserved

 Trotec Laser GmbH

Page 32 of 61

Note: Shift + Up will cause the head moving backwards to the light barriers (according

simultaneous pressing of both z-keys).

If any of positioning keys X and Y is pressed, no moves in Z are possible.

An automatic move of the Z- axis can be stopped by pressing of the positioning keys

(1 or 2).

2 POSITIONING KEYS X/Y

Use the positioning keys to manually move the lens holder into the indicated directions.

When you press two keys simultaneously, the lens holder moves diagonally.

When you press the "Shift" key and one of the positioning keys simultaneously,

a movement to the corresponding end position is performed.

If all panels are closed, the movement is done with the maximum velocity, if

opened, the speed is 1/4th of the maximum.

While the Z- axis is in movement (e.g. autofocus), no cursor moves in X and Y axis are

performed.

3 START / PAUSE / REPEAT

Pressing the button with no Job running the actual Jobs positioned on the selected plate in

JobControl are started.

Used to pause the current working process (key lights up). As soon as the last processing

command is finished, the motion system stops.

If this key is pressed a second time, the key illumination goes off, the interrupted working

process is continued.

Pressing the button after a Job is finished will repeat the actual Jobs positioned on the

selected plate in JobControl. The Jobs will reset automatically

4 STANDBY

Switches the device into Standby mode (Laser ready, illumination off) - key lights

up.

By pressing the key again the device is switched back to Ready mode.

If the Standby button is pressed while the Z- axis is in an automatic move (e.g. autofocus),

the Standby mode is entered after finishing the Z- axis- move (Z- axis move can be stopped

by pressing any of the Z- axis keys).

5 EXHAUST

Used to manually switch the exhaust system on and off.
