![Trotec Speedy 500 Инструкция по эксплуатации онлайн [33/61] 338813](/views2/1404710/page33/bg21.png)
8023 | V5.0_EN (11/2015)
Technical changes reserved
Trotec Laser GmbH
Page 33 of 61
The key illumination shows the status of the exhaust system. When the key is illuminated,
the exhaust system is switched on.
After completing the engraving process, the exhaust system can only be switched off after
some seconds (follow-up time).
6 "SHIFT" key for 2nd function key level
For additional Operations. When this key is pressed together with the following
keys, the functions indicated are activated:
Exhaust (5): Air assist on/off
Positioning keys X/Y/Z (2): These keys drive the laser head to
the end position
7 STOP
By pressing this button, the actual process running will be stopped.
8 STATUS INDICATOR LASER BEAM
Indicates, that a laser beam is currently being emitted.
9 STATUS DISPLAY
Indicates the current status of the device.
green, flashing slowly (0.5 Hz)
9
Machine is ready
green, flashing fast (2 Hz)
9
Cover has been opened
green permanent light / Pause mode
9
Data available in the machine
red permanent light
8
Laser beam is being emitted
green/red flashing alternately
8+9
Cover open during switch-on
process, simultaneously acoustic
signal - no referencing
10 HOME
Pressing this button will change the machines homeposition temporary (Home-
move to this position)
