8023 | V5.0_EN (11/2015)
Technical changes reserved
Trotec Laser GmbH
Page 37 of 61
To C - Automatic focusing by means of light barriers (optional):
The automatic focusing is only possible if the work piece is thicker than the
rulers.
The Autofocus option might not work on transparent materials or materials
which are not flat.
Bear in mind that defects from head crashes (working head hits material or
working table) are NOT warranted.
By pressing the two keys for Z positioning of the working table simultaneously, the laser
beam is automatically focused onto the work piece (If you don't have the autofocus-option,
the table will go down to Z = 0).
1
