SpeedMarker 300
8037 | V 2.1_EN (01/2016)
24/ 51
Workstation
Interior dimensions (W x D)
350 x 400 mm²
Dimension of opening (W x H)
350 x 383 mm²
Door
manual
Maximum part size (W x D)
350 x 400 mm²
Maximum part height
(Depending on lens)
* 16mm with optional high-speed scanner
250 mm
F-100
171 mm
F-160
22 mm*
F-254
Maximum load
25 kg
Table
Aluminum t-slot table (Isel PT 25) 375 x 400 mm²
Z-axis
Mechanical or software-controlled Z-axis
Traveling distance Z-axis
250 mm
Pass-through option (W x H)
200 x 165 mm²
Color
RAL 3002, RAL 7016, RAL 7035
Control
Computer
Industrial PC as 19" rack unit, 3RU high, 4 GB RAM, HDD 250 GB, DVD
ROM, Windows
®
7
Interfaces
USB, Ethernet, RS232,
Interfaces laser
Laser-interlock, marking-start (24 VDC), marking-stop (24 VDC),
E-Stop, Error-Reset, Laser-Busy, optional digital I/O’s (24 VDC),
Software
SpeedMark
