7 Installation

Installation environment

 The ambient air temperature must be between +15°C und +35°C and the relative air

o humidity not exceed 90% (non-condensing).

 If the system has been subject to significant temperature variations, it must be brought back to

room temperature before being commissioned.

 A laser system consists of high quality electrical and optical components. Mechanical

stresses, vibrations and impacts must always be avoided.

 There must be sufficient air supply to both 19” modules. The accumulation of heat due to cov-

ered ventilation slots or filter pads can damage the system.

Installation SpeedMarker 300

1. Remove the entire packaging material.

2. Remove all transport protection.

3. The machine must stand upright.

4. Check if the laser protection glass is intact.

5. Now connect the electrical components (see the following steps).

All connectors are clearly identified in order to facilitate the electrical installation. A con-

nector marked X43 belongs to the socket with the same denotation.

The connector denotations are also coded. The last digit of the connector denotation iden-

tifies the respective hardware components. Therefore:

X …1 Laser module

X …2 Marking head

X …3 PC

The laser module and the PC should be located next to or directly above one another if

possible in order for the modules to be connected to one another with the cables provided..
