SpeedMarker 300
8037 | V 2.1_EN (01/2016)
28/ 51
Storage
Keep the machine sealed in its packaging until it gets assembled/installed.
Store packed items only under the following conditions:
The storage location must be dry, free of dust, caustic materials, vapors and combustible materials
Store in a storage room or packaged with adequate weather protection.
Avoid subjecting the machine to shocks.
Storage conditions:
Storage temperature: +0 bis +40°C (+0 to104°F)
Relative humidity: max. 85%
Avoid extreme temperature fluctuations.
Take particular care when packing away electronic components.
When storing for a longer period apply a coat of oil to all machine parts open to rusting. Regularly check
the overall condition of all parts and packaging.
Plant-internal transport (repositioning the machine)
The SpeedMarker needs to be transported in an upright position; avoid any strong vibrations.
1. Shut off the machine.
2. Unplug the electrical supply.
3. Remove the exhaust system.
4. Reposition and park the machine on clean, solid level ground again.
5. Adjust the machine, setup the electrics and carry out a performance test.
CAUTION
When transporting the machine over great distances the original transport box including interior pro-
tection needs to be used.
