Trotec SpeedMarker 300 [48/51] Troubleshooting
![Trotec SpeedMarker 300 [48/51] Troubleshooting](/views2/1404721/page48/bg30.png)
SpeedMarker 300
8037 | V 2.1_EN (01/2016)
48/ 51
10 Troubleshooting
This chapter should assist maintenance personnel with the identification and resolution of operational faults based
on error messages and symptoms.
ATTENTION
Repairing faults incorrectly can cause serious injury or damage. For this reason, this work may only
be carried out by by authorized, trained personnel who are familiar with how to operate the machine
and in strict observance of all safety instructions.
INFO
Movements and functions may only be performed when there are no errors and all devices are ready
for operation. This state is prerequisite for starting the SpeedMarker 300. If this state changes during
operation, the laser cell stops.
The error must be acknowledged using the “ON” button on the keypad.
Errors, cause and resolution
Problem
Possible Cause
Resolution
Not possible to turn on laser
rack
System switched off
Turn on main switch
The key is missing from the key switch
on the laser rack or is in the vertical
position.
Place the key in the switch on the laser
rack and turn to the horizontal position
System power plug not installed cor-
rectly
Check the System power plug has been
installed correctly
Incorrect or no voltage supply to the
System
Check the System 230/110V power sup-
ply
Laser rack power plug not installed
correctly
Check the laser rack power plug has been
installed correctly
Faulty fuse in laser power supply
Replace fuse
When option pass-through:
Emergency stop button has been acti-
vated
Release the emergency stop button
Not possible to turn on the
SpeedMarker
Emergency stop button has been acti-
vated
Release the emergency stop button
System power plug not installed cor-
rectly
Check the System power plug has been
installed correctly
Incorrect or no voltage supply to the
System
Check the SpeedMarker 230/110V power
supply
