SpeedMarker 300
8037 | V 2.1_EN (01/2016)
49/ 51
Problem
Possible Cause
Resolution
Error message on
loading the program
Plug or cable not installed correctly
Check the plug and cable are installed
correctly
Check the installation
Laser power supply switched off
Turn on main switch
Software not installed correctly
Re-install software
Software terminated irregularly
Restart PC
No laser beam
Laser not in focus
Check working distance
Shutter is closed
Open shutter - if not possible
check interlock circuit
Incorrect laser parameters
Check the parameters in the program.
Use suitable parameters for the material
and application
Focussing lens dirty
Check the lens for dirt and clean as re-
quired.
Insufficient laser output
Laser not in focus
Check working distance
Incorrect laser parameters
Check the parameters in the program.
Use suitable parameters for the material
and application
Focussing lens dirty
Check the lens for dirt and clean as re-
quired.
Missing symbols
Focussing lens dirty
Check the lens for dirt and clean as re-
quired.
Surface of the material dirty
Clean material surface
The marking plane is not parallel to
the focussing lens
Ensure that the entire marking surface is
parallel to the focussing lens
Other faults
Contact TROTEC Support
