5 Transport, packaging and storage

Safety instructions

WARNING

There is a risk of injury as a result of falling parts while transporting, loading or unloading the machine.

CAUTION

The machine can be damaged or destroyed if it is subject to improper handling during transport.

For this reason the following safety instructions must be observed:

Almost move the machine with the utmost care and precausion.

Consider the machine's centre of gravity when transporting it (minimize the risk of it tipping over).

Take measures to prevent the machine from slipping sideways.

Transport the machine as carefully as possible in order to prevent damage.

When transporting the machine overseas, ensure that the packaging is airtight.

Protect the machine against transportation damage using straps and inserts, and leave sufficient distance

between other transported items.

Do not place any heavy loads on the machine or machine components.

Ambient temperature for transportation:

Min. temp. 10 °C

Max. temp. 40 °C

Scope of supply (standard configuration)

 1x SpeedMaker 300 (incl. laser module)

 1x Industrial Computer

 2x Key for Industrial Computer

 2x Key for laser module

 1x Connection cable set:

o Cable W203 (X51 – X53).

o Cable W503 (X93 – X103)

o Back bridge Plug (X31)

o X11 plug (wired)

 1x CD with marking software

 1x Windows Backup

 1x Lens cleaning kits

 1x Allen key set

 2x Power cord for laser module and computer

 1x Power cord for electrical Z-axis (optional)

 1x Extraction system connection cable (optional)

 1x Pass-Through interlock key (optional)

 2x: Additional weights when side panels released (for Pass-Through only)
