Chillers ULTIMA COMPACT FREECOOL
Chillers
Installation & Maintenance : 903-132 TM E 06/05/A
17
Installation Data
WATER SYSTEM
UCFC75D-2/1 UCFC100D-2/1 UCFC125D-3/1 UCFC150D-3/1 UCFC160D-6/2
Connections
Water Inlet / Outlet (1) DN65 DN65 DN65 DN65 DN80
Water Drain/Bleed in 1/2 1/2 1/2 1/2 1/2
Water System
Min. System Water Volume (2) l 377 469 419 727 717
Max. System Press Bar 10 10 10 10 10
OPTIONAL EXTRAS
Water Pump (3) (4) In Line Pump
Nom External Head Std Single /
R&S
kPa
143 109 145 122 187
Nom External Head Larger
Single/R&S
kPa
184 150 190 185 254
Nom External Head Standard
Twin
kPa
100 82 88 89 184
Nom External Head Larger Twin kPa 146 125 133 152 254
Pressurisation Unit
Water Inlet Connection in 1/2 1/2 1/2 1/2 1/2
UCFC180D-6/2 UCFC200D-6/2 UCFC225D-6/2 UCFC250D-8/2 UCFC275D-8/2
Connections
Water Inlet / Outlet (1) DN80 DN80 DN80 DN80 DN100
Water Drain/Bleed in 1/2 1/2 1/2 1/2 1/2
Water System
Min. System Water Volume (2) l 645 715 811 1156 1004
Max. System Press Bar 10 10 10 10 10
OPTIONAL EXTRAS
Water Pump (3) (4) In Line Pump
Nom External Head Std Single /
R&S
kPa
169 160 151 136 163
Nom External Head Larger
Single/R&S
kPa
236 226 217 201 228
Nom External Head Standard
Twin
kPa
166 156 147 130 157
Nom External Head Larger Twin kPa 235 225 215 199 225
Pressurisation Unit
Water Inlet Connection in 1/2 1/2 1/2 1/2 1/2
UCFC300D-8/2 UCFC330D-10/2 UCFC360D-10/2 UCFC400D-12/2 UCFC450D-12/2
Connections
Water Inlet / Outlet (1) DN100 DN100 DN100 DN100 DN100
Water Drain/Bleed in 1/2 1/2 1/2 1/2 1/2
Water System
Min. System Water Volume (2) l 1374 1168 1122 1337 1395
Max. System Press Bar 10 10 10 10 10
OPTIONAL EXTRAS
Water Pump (3) (4) In Line Pump
Nom External Head Std Single /
R&S
kPa
151 138 121 125 108
Nom External Head Larger
Single/R&S
kPa
218 206 190 196 182
Nom External Head Standard
Twin
kPa
144 129 110 109 87
Nom External Head Larger Twin kPa 213 198 180 181 161
Pressurisation Unit
Water Inlet Connection in 1/2 1/2 1/2 1/2 1/2
(1) Flanged to PN16.
(2) For minimum system volume refer to the Technical Manual.
(3) Based on 12/7°C water temperature and 30°C ambient with a 20% Ethylene Glycol Water Concentration.
(4) Figures based on D Model, for DQ & DSQ details, please contact Airedale.
