Chillers ULTIMA COMPACT FREECOOL
Chillers
Installation & Maintenance : 903-132 TM E 06/05/A
21
Installation Data
ELECTRICAL DATA
UCFC180D-6/2 UCFC200D-6/2 UCFC225D-6/2 UCFC250D-8/2 UCFC275D-8/2
Unit Data
Nominal Run Amps (1) A 109 121 131 146 160
Maximum Start Amps (2) A 297 358 368 383 440
Permanent Supply VAC 230 V 1 PH 50 Hz
Mains Supply VAC 400 V 3 PH 50 Hz
Rec Permanent Fuse Size A 16 16 16 16 16
Rec Mains Fuse Size A 160 160 200 200 200
Max Permanent Incoming Cable
Size
mm²
4 mm² terminals
Max Mains Incoming Cable Size mm² Direct to Bus Bar
Control Circuit VAC 24V/230VAC
Evaporator
Pad Heater Rating W 100 100 100 100 100
External Trace Heating
Available (fitted by others) W 500 500 500 500 500
Condenser Fan - Per Fan
Full Load Amps A 1.75 1.75 1.75 1.75 1.75
Locked Rotor Amps A 6.20 6.20 6.20 6.20 6.20
Motor Rating kW 0.98 0.98 0.98 0.98 0.98
Compressor - Per Compressor
Quantity 2 + 2 2 + 2 2 + 2 4 2 + 2
Motor Rating kW 15.0 / 11.7 18.2 / 11.7 18.2 / 15.0 18.2 22.8 / 18.2
Nominal Run Amps (1) A 27.0 / 22.0 33.0 / 22.0 33.0 / 27.0 33.0 40.0 / 33.0
Sump Heater Rating W 130.0 / 75.0 130.0 / 75.0 130.0 / 130.0 130.0 130.0 / 130.0
Start Amps (2) 215.0 / 175.0 270.0 / 175.0 270.0 / 215.0 270.0 320.0 / 270.0
Type Of Start Direct on line
QUIET DQ UCFC180DQ-6/2 UCFC200DQ-6/2 UCFC225DQ-8/2 UCFC250DQ-8/2 UCFC275DQ-10/2
All data as above except:
Condenser Fan - Per Fan
Full Load Amps A 1.15 1.15 1.15 1.15 1.15
Locked Rotor Amps A 2.10 2.10 2.10 2.10 2.10
Motor Rating kW 0.70 0.70 0.70 0.70 0.70
SUPER QUIET DSQ UCFC180DSQ-8/2 UCFC200DSQ-8/2 UCFC225DSQ-10/2 UCFC250DSQ-10/2 UCFC275DSQ-12/2
All data as above except:
Condenser Fan - Per Fan
Full Load Amps A 0.83 0.83 0.83 0.83 0.83
Locked Rotor Amps A 1.50 1.50 1.50 1.50 1.50
Motor Rating kW 0.32 0.32 0.32 0.32 0.32
OPTIONAL EXTRAS
Power Factor Correction
Nominal Run Amps (1) A 99 111 119 134 146
Maximum Start Amps (2) A 290 351 359 374 430
Recommended Mains Fuse A 125 160 160 200 200
Compressor Nominal Run
Amps - Per Compressor
A
2 x 24/2 x 20 2 x 30/2 x 20 2 x 30/2 x 24 4 x 30 2 x 36 / 2 x 30
Electronic Soft-Start
Nominal Run Amps (1) A 109 121 131 146 160
Maximum Start Amps (2) A 211 250 260 275 312
Recommended Mains Fuse A 160 160 200 200 200
Single Head Pump (or Run/Standby)
Unit Nominal Run Amps (1) A 113 125 133 133 161
Recommended Mains Fuse A 160 200 200 200 250
Motor Rating kW 7.5 7.5 7.5 7.5 7.5
Full Load Amps
A 14.7 14.7 14.7 14.7 14.7
Larger Single Head Pump
(Or Run/Standby)
Unit Nominal Run Amps (1) A 120 132 140 155 167
Recommended Mains Fuse A 160 200 200 200 250
Motor Rating kW 11 11 11 11 11
Full Load Amps
A 21.4 21.4 21.4 21.4 21.4
Twin Head Pump
Unit Nominal Run Amps (1) A 113 125 133 133 161
Recommended Mains Fuse A 160 200 200 200 250
Motor Rating kW 7.5 7.5 7.5 7.5 7.5
Full Load Amps
A 14.7 14.7 14.7 14.7 14.7
Larger Twin Head Pump
Unit Nominal Run Amps (1) A 120 132 140 155 167
Recommended Mains Fuse A 160 200 200 200 250
Motor Rating kW 11 11 11 11 11
Full Load Amps
A 21.4 21.4 21.4 21.4 21.4
(1) Based at 12/7°C water and 30°C ambient
(2) Starting amps refers to the direct on line connections.
