Airedale UCFC 125 [41/46] Ultima compact freecool
![Airedale UCFC 125 [41/46] Ultima compact freecool](/views2/1409444/page41/bg29.png)
40
Installation & Maintenance : 903-132 IM E 06/05/A
Chillers
ULTIMA COMPACT FREECOOL
Chillers
SPARES
1 Discharge Line Ball Valve
2 Discharge Shraeder Connection
3 HP Switch
3a Head Pressure Control Solenoid Valve Set (behind panel)
4 Compressor Electrical Terminal Box
5 Oil Level Sight Glass
6 Sump Heater
7 Liquid Line Filter Drier
8 Electronic Expansion Valve
9 Liquid Line Sight Glass
10 Liquid Line
11 Discharge Thermostat Switch
12 Low Pressure Switch
13 Suction Pressure Transducer
14 Suction Port
15 Oil Sump Drain Point
16 Compressor Feet/Resilient Mounts
17 Water Inlet Sensor
18 Evaporator
18a Isolating valves for maintenance
18b Free Cooling Control Valve & Actuator
18c Run/Standby Pump Set (Optional Extra)
19 Flow Switch
19a Water Filter
20 Compressor Compartment
21 Evaporator, Waterside & Optional Pump Compartment
22 Water Inlet Flange Connection
23 Water Outlet Flange Connection
24 Mains Panel
25 Door Interlocking isolator
26 Emergency Stop
27 Incoming Customer Mains Access Points
28 Condenser Coils
29 Unit Controller Panel
30 Fan Contactor MPCB
31 Modulating Head Pressure Controller
32 Compressors MCBs
33 Condenser Fan MPCB
34 Compressor Contactors
35 Isolator
36 Incoming Customer Mains 3 Phase
37 Microprocessor Controller
38 Electronic Expansion Valve Controller
39 Customer Permanent Supply/Controls Connections
40 EMC Filter
The serial plate can be located inside Item 24.
A
spares list for 1, 3 and 5 years will be supplied with every unit and is also available
from our Spares department on request.
For ease of identification when ordering spares or contacting Airedale about your unit,
please quote the unit type, unit serial number and the date of manufacture, which can be
found on the unit serial plate.
Parts Identification
