ULTIMA COMPACT FREECOOL Chillers
Chillers
28
Installation & Maintenance : 903-132 IM E 06/05/A
Commissioning Data
GENERAL DATA
Operating Limits
Unit With Electronic Fan Speed HP Control (-20°C)
Minimum ambient air db °C -20°C
Maximum ambient air db °C Refer to Technical Manual - Performance Data - Capacity Data
Minimum leaving water temperature °C +6C
Maximum return water temperature °C +20°C
1 Temperatures lower than those stated can be obtained with additional glycol.
2 For conditions outside those quoted, please refer to Airedale.
MECHANICAL DATA
Oil & Refrigerant Charges
UCFC75D-2/1 UCFC100D-2/1 UCFC125D-3/1 UCFC150D-3/1 UCFC160D-6/2
Compressor Tandem Scroll
Quantity 4 4 4 4 4
Oil Charge Volume (Total) l 3.25 + 3.25 3.80 + 3.80 6.20 + 3.80 6.20 + 6.20 4 x 6.2
Oil Type Polyol Ester
Refrigeration Dual Circuit
Refrigerant Control Electronic Expansion Valve
Refrigerant Precharged R407C
Charge (Total) kg 22 + 22 22 + 22 30 + 30 30 + 30 29 + 29
QUIET DQ UCFC75DQ-2/1 UCFC100DQ-3/1 UCFC125DQ-3/1 UCFC150DQ-4/1 UCFC160DQ-6/2
Refrigerant Charge (Total) kg 22 + 22 30 + 30 30 + 30 40 + 40 29 + 29
SUPER QUIET DSQ UCFC75DSQ-2/1 UCFC100DSQ-3/1 UCFC125DSQ-4/1 UCFC150DSQ-4/1 UCFC160DSQ-8/2
Refrigerant Charge (Total) kg 22 + 22 30 + 30 40 + 40 40 + 40 37 + 37
UCFC180D-6/2 UCFC200D-6/2 UCFC225D-6/2 UCFC250D-8/2 UCFC275D-8/2
Compressor Tandem Scroll
Quantity 4 4 4 4 4
Oil Charge Volume (Total) l 2 x 8.0 / 2 x 6.2 2 x 8.0 / 2 x 6.2 4 x 8.0 4 x 8.0 4 x 8.0
Oil Type Polyol Ester
Refrigeration Dual Circuit
Refrigerant Control Electronic Expansion Valve
Refrigerant Precharged R407C
Charge (Total) kg 29 + 29 29 + 29 29 + 29 38 + 38 39 + 39
QUIET DQ UCFC180DQ-6/2 UCFC200DQ-6/2 UCFC225DQ-8/2 UCFC250DQ-8/2 UCFC275DQ-10/2
Refrigerant Charge (Total) kg 29 + 29 29 + 29 37 + 37 38 + 38 46 + 46
SUPER QUIET DSQ UCFC180DSQ-8/2 UCFC200DSQ-8/2 UCFC225DSQ-10/2 UCFC250DSQ-10/2 UCFC275DSQ-12/2
Refrigerant Charge (Total) kg 37 + 37 37 + 37 45 + 45 45 + 45 54 + 54
UCFC300D-8/2 UCFC330D-10/2 UCFC360D-10/2 UCFC400D-12/2 UCFC450D-12/2
Compressor Tandem Scroll Trio Scroll
Quantity 4 6 6 6 6
Oil Charge Volume (Total) l 4 x 8.0 6 x 8.0 6 x 8.0 6 x 8.0 6 x 8.0
Oil Type Polyol Ester
Refrigeration Dual Circuit
Refrigerant Control Electronic Expansion Valve
Refrigerant Precharged R407C
Charge (Total) kg 39 + 39 49 + 45 47 + 47 57 + 53 56 + 56
QUIET DQ UCFC300DQ-10/2 UCFC330DQ-12/2 UCFC360DQ-12/2 UCFC400DQ-14/2 UCFC450DQ-14/2
Refrigerant Charge (Total) kg 47 + 47 57 + 53 55 + 55 66 + 60 64 + 64
SUPER QUIET DSQ UCFC300DSQ-12/2 UCFC330DSQ-16/2 UCFC360DSQ-16/2 UCFC400DSQ-16/2 UCFC450DSQ-16/2
Refrigerant Charge (Total) kg 54 + 54 74 + 68 71 + 71 74 + 68 72 + 72
