ULTIMA COMPACT FREECOOL Chillers
Chillers
22
Installation & Maintenance : 903-132 IM E 06/05/A
Installation Data
ELECTRICAL DATA
UCFC300D-8/2 UCFC330D-10/2 UCFC360D-10/2 UCFC400D-12/2 UCFC450D-12/2
Unit Data
Nominal Run Amps (1) A 173 198 216 240 260
Maximum Start Amps (2) A 454 435 453 520 540
Permanent Supply VAC 230 V 1 PH 50 Hz
Mains Supply VAC 400 V 3 PH 50 Hz
Rec Permanent Fuse Size A 16 16 16 16 16
Rec Mains Fuse Size A 250 250 315 315 355
Max Permanent Incoming Cable
Size
mm²
4 mm² terminals
Max Mains Incoming Cable Size mm² Direct to Bus Bar
Control Circuit VAC 24V/230VAC
Evaporator
Pad Heater Rating W 100 100 100 100 100
External Trace Heating
Available (fitted by others) W 500 500 500 500 500
Condenser Fan - Per Fan
Full Load Amps A 1.75 1.75 1.75 1.75 1.75
Locked Rotor Amps A 6.20 6.20 6.20 6.20 6.20
Motor Rating kW 0.98 0.98 0.98 0.98 0.98
Compressor - Per Compressor
Quantity 4 3 + 3 6 3 + 3 6
Motor Rating kW 22.8 18.2 / 15.0 18.2 22.8 / 18.2 22.8
Nominal Run Amps (1) A 40.0 33.0 / 27.0 33.0 40.0 / 33.0 40.0
Sump Heater Rating W 130.0 130.0 / 130.0 130.0 130.0 / 130.0 130.0
Start Amps (2) 320.0 270.0 / 215.0 270.0 320.0 / 270.0 320.0
Type Of Start Direct on line
QUIET DQ UCFC300DQ-10/2 UCFC330DQ-10/2 UCFC360DQ-12/2 UCFC400DQ-12/2 UCFC450DQ-14/2
All data as above except:
Condenser Fan - Per Fan
Full Load Amps A 1.15 1.15 1.15 1.15 1.15
Locked Rotor Amps A 2.10 2.10 2.10 2.10 2.10
Motor Rating kW 0.70 0.70 0.70 0.70 0.70
SUPER QUIET DSQ UCFC300DSQ-12/2 UCFC330DSQ-14/2 UCFC360DSQ-14/2 UCFC400DSQ-16/2 UCFC450DSQ-16/2
All data as above except:
Condenser Fan - Per Fan
Full Load Amps A 0.83 0.83 0.83 0.83 0.83
Locked Rotor Amps A 1.50 1.50 1.50 1.50 1.50
Motor Rating kW 0.32 0.32 0.32 0.32 0.32
OPTIONAL EXTRAS
Power Factor Correction 158 180 198 219 237
Nominal Run Amps (1) A 442 420 438 503 521
Maximum Start Amps (2) A 250 250 250 250 315
Recommended Mains Fuse A 4 x 36 3 x 30 / 3 x 24 6 x 30 3 x 36 / 3 x 30 6 x 36
Compressor Nominal Run
Amps - Per Compressor
A
158 180 198 219 237
Electronic Soft-Start
Nominal Run Amps (1) A 173 198 216 240 260
Maximum Start Amps (2) A 326 327 345 392 412
Recommended Mains Fuse A 250 250 315 315 355
Single Head Pump (or Run/Standby)
Unit Nominal Run Amps (1) A 173 194 212 234 252
Recommended Mains Fuse A 250 315 315 315 355
Motor Rating kW 7.5 7.5 7.5 7.5 7.5
Full Load Amps
A 14.7 14.7 14.7 14.7 14.7
Larger Single Head Pump
(Or Run/Standby)
Unit Nominal Run Amps (1) A 179 201 219 240 258
Recommended Mains Fuse A 250 315 315 315 355
Motor Rating kW 11 11 11 11 11
Full Load Amps
A 21.4 21.4 21.4 21.4 21.4
Twin Head Pump
Unit Nominal Run Amps (1) A 173 194 212 234 252
Recommended Mains Fuse A 250 315 315 315 355
Motor Rating kW 7.5 7.5 7.5 7.5 7.5
Full Load Amps
A 14.7 14.7 14.7 14.7 14.7
Larger Twin Head Pump
Unit Nominal Run Amps (1) A 179 201 219 240 258
Recommended Mains Fuse A 250 315 315 315 355
Motor Rating kW 11 11 11 11 11
Full Load Amps
A 21.4 21.4 21.4 21.4 21.4
(1) Based at 12/7°C water and 30°C ambient
(2) Starting amps refers to the direct on line connections.
