ULTIMA COMPACT FREECOOL Chillers
Chillers
8
Installation & Maintenance : 903-132 IM E 06/05/A
General Description
OPTIONAL EXTRAS – ENERGY SAVING
Power Factor Correction
When applied to the motors of each compressor, the compressor power factor is
controlled to a minimum operating value of 0.95 at the full operating capacity. This
satisfies many supply authorities that may impose surcharges on equipment with power
factor less than 0.95.
OPTIONAL EXTRAS – GENERAL
• Anti Vibration Mounts
Loose Item
• Condenser Fan Discharge Air Plenum Extension
Instructions supplied with
item
Factory Fitted
• Epoxy Coated Condenser Coils
• Coil Guards
• Sequence Control
CAUTION
It is only possible to set up sequencing following completion of
interconnecting communication wiring. Airedale Service can
arrange Sequence setup on request.
• BMS Interface Card
• Dual Pressure Relief Valve
• Leak Detection Kit
• Electronic Soft Start
• Power Factor Correction
• Differential Pressure Switch
• Remote Setpoint Adjust
• Flushing Bypass Kit (Incl. Shut off & Water Regulating Valve)
• Integral Pump Packages
• Mini Pressurisation Package
• Alternative Refrigerant (Outside EU)
• Commissioning
OPTIONAL UNIT COVER
• Chillerguard® Maintenance
For details and a competitive quotation,
contact Airedale Service.
