![D-Link DES-3326SR Инструкция по эксплуатации онлайн [156/240] 40462](/views2/1043774/page156/bg9c.png)
D-Link DES-3326SR Layer 3 Switch
The following fields can be set:
Parameter Description
VLAN Name
Allows the entry of the name of the VLAN for which IGMP Snooping is to be
configured.
Query Interval
Allows the entry of a value between 1 and 65500 seconds, with a default of
125 seconds. This specifies the length of time between sending IGMP
queries.
Max Response
Sets the maximum amount of time allowed before sending an IGMP
response report. A value between 1 and 25 seconds can be entered, with a
default of 10 seconds.
Robustness Variable
A tuning variable to allow for sub-networks that are expected to lose a large
number of packets. A value between 2 and 255 can be entered, with larger
values being specified for sub-networks that are expected to lose larger
numbers of packets.
Last Member Query
Interval
Specifies the maximum amount of time between group-specific query
messages, including those sent in response to leave group messages. The
default is 1 second.
Querier State
This field can be switched using the pull-down menu between Disabled and
Enabled.
Host Timeout
Specifies the maximum amount of time a host can be a member of a
multicast group without the switch receiving a host membership report. The
default is 260 seconds.
Host Leave Timer
Specifies the maximum amount of time between the switch receiving a leave
group message from a host, and the switch issuing a group membership
query. If the switch does not receive a response from the group membership
query before the Host Leave Timer expires, the host address is deleted from
the switch’s forwarding table. The default is 2 seconds.
Route Timeout
Specifies the maximum amount of time a route will remain in the switch’s
forwarding table without receiving a membership report. The default is 260
seconds.
State <Disabled>
This field can be switched using the pull-down menu between Disabled and
Enabled. This is used to enable or disable IGMP Snooping for the specified
VLAN.
146
