D-Link DES-3326SR Layer 3 Switch
Use the descriptions here as a guide to set up the System Log Server settings.
Parameter Description
Index
Syslog server settings index (1-4).
Server IP
Type in the IP address of the Syslog server receiving the message.
Severity
Select the level of message sent, select: Warning, Information or All.
Facility
Some of the operating system daemons and processes have been assigned
Facility values. Processes and daemons that have not been explicitly
assigned a Facility may use any of the "local use" facilities or they may use
the "user-level" Facility. Those Facilities that have been designated are
shown in the following: Bold font means the facility values the switch
supports now.
Numerical Facility
Code
0 kernel messages
1 user-level messages
2 mail system
3 system daemons
4 security/authorization messages
5 messages generated internally by syslog line printer subsystem
7 network news subsystem
8 UUCP subsystem
9 clock daemon
10 security/authorization messages
11 FTP daemon
12 NTP subsystem
13 log audit
14 log alert
15 clock daemon
16 local use 0 (local0)
17 local use 1 (local1)
18 local use 2 (local2)
19 local use 3 (local3)
20 local use 4 (local4)
21 local use 5 (local5)
22 local use 6 (local6)
23 local use 7 (local7)
UDP Port
Type the UDP port number used for sending Syslog messages. The default
is 514.
Status
Choose Enabled or Disabled to activate or deactivate this
73
