2 3
OPERATION INSTRUCTIONS
! WARNING
To prevent accidents and machine damage,
read these instructions before installation and
use.
SAFETY INSTRUCTIONS
THIS CLEANER IS INTENDED FOR
HOUSEHOLD USE ONLY.
IMPORTANT SAFETY INSTRUCTIONS
When you use an appliance, basic
precautions should always be followed,
including the following:
1. READ ALL INSTRUCTIONS BEFORE
USING THE APPLIANCE.
2. ALWAYS FOLLOW THESE SAFETY
INSTRUCTIONS.
3. BRING CLEANER TO UPRIGHT
POSITION WHEN USING THE HOSE
AND ATTACHMENTS.
4. DO NOT LEAVE CLEANER
UNATTENDED
5. REGULARLY CHECK THE FILTER TO
CLEAN OR REPLANCE.
6. WARNING: DO NOT USE SHARP
OBJECTS TO CLEAN OUT THE HOSE
SINCE THEY COULD CAUSE DAMAGE.
7. OCCASIONALLY REMOVE BRUSH AND
CLEAN DEBRIS FROM END CAPS TO
KEEP BRUSH ROTAING SMOOTHLY.
IMPORTANT SAFETY INSTRUCTIONS
WHEN PLUGGED IN. READ ALL
INSTRUCTIONS BEFORE USING THE
APPLIANCE.
WARNING: TO REDUCE THE RISK OF
FIRE, ELECTRIC SHOCK OR INJURY:
1. Do not leave appliance when plugged in.
Unplug from outlet when not in use and
before servicing.
2. Do not allow to be used as a toy. Close
attention is necessary when used by or
near child.
3. Use only as described in this manual.
Use only manufacture‘s recommended
attachments.
4. Do not use with damaged cord oy plug. If
appliance is not working as it should, has
been dropped, damaged, left outdoors, or
dropped into water, return it to a service
center for inspection.
5. Do not pull or carry by cord, use cord as
handle, close a door on cord, or pull cord
around shape edges or corners. Do not
run appliance over cord. Keep cord away
from heated surface.
6. Do not unplug by pulling on cord. To
unplug, grasp the plug, not the cord.
7. Do not handle plug or appliance with wet
hands.
8. Do not put any object into openings. Do
not use with any opening blocked; keep
free of dust, lint, hair, and anything that
may reduce air ow.
9. Keep hair, loose clothing, ngers, and all
parts of body away from openings and
moving parts.
10. Do not pick up anything that is burning or
smoking, such as cigarettes, matches, or
hot ashes.
11. Turn off all controls before unplugging.
12. Use with extra care when cleaning on
stairs.
13. Do not use to pick up ammable or
combustible liquids, such as gasoline, or
use in area where they may be present.
14. Keep the vacuum cleaner on the oor.
Only the hand-held vacuum cleaners may
be set on furniture.
15. Do not use an extension cord with this
vacuum cleaner.
16. Store the vacuum cleaner indoors. Put the
vacuum cleaner away after use to present
tripping accidents.
17. Using improper voltage may result in
damage to the motor and possible injury
to the user. Proper voltage is listed on the
cleaner plate.
18. This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision
or instruction concerning use of the
appliance by a person responsible for
their safety.
19. Children should be supervised to ensure
that they do not play with the appliance.
20. If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualied persons in
order to avoid a hazard.
*NOT AVAILABLE ON ALL MODELS.
Correct Disposal of this product
This marking indicates that this product
should not be disposed with other
household wastes throughout the EU.
To prevent possible harm to the
environment or human health from
uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse
of material resources.
To return your used device, please use the
return and collection systems or contact the
retailer where the product was purchased.
They can take this product for environmental
safe recycling.
FEATURES (Refer to Fig. A)
1. Dust Brush
2. Crevice Tool
3. Floor Brush
4. Adjustable Tube
5. Hook
6. Curved Tube
7. Handle
8. Main Body
9. Hose Inserter
10. Barrel
11. Base
12. Wheel
13. Buckle Assembly
14. Clapboard Assembly
15. Power Switch
16. Hose
HOW TO ASSEMBLE
1. Release the buckle and remove the main
body. (Refer to Fig. 1)
2. Lift the Clapboard Assembly and unpack
the wheel and attachment from the Barrel
(Refer to Fig. 2)
3. Insert these wheels into the hole of base
in turn, then press down and make sure
the wheel are rm (Refer to Fig. 3)
4. Put down the clapboard assembly. (Refer
to Fig. 4)
5. Insert 1 of the main body into 2 of barrel,
and then lock the buckle. (Refer to Fig. 5)
6. Insert hose inserter of the hose assembly
into barrel or 1 of main body, then gently
rotate to the right ; and make sure they
are tted tightly. (Refer to Fig. 6)
CAUTION:
#1 of main body is used to blowing.
7. Insert adjustable tube into hook, and
adjust it to the proper location, then t it
with screw. (Refer to Fig. 7)
8. Insert curved Tube of the hose assembly
into adjustable tube; and make sure the
connection is rm. (Refer to Fig. 8)
9. Insert the extention tube into oor brush;
and make sure the connection is rm.
(Refer to Fig. 9)
HOW TO OPERATE
WARNING: FULLY ASSEMBLE CLEANER
BEFORE OPERATING.
On/off switch
Turn on/off the unit by pressing the power
switch on the top of it.
Caution: Before using the vacuum cleaner to
load 2.5 liters of water. (Refer to Fig. 10)
Air Flow Control
Adjust the suction by adjusting the pusher up
and down.
Caution: stop the cleaner and cut off the
power supply before change the accessories.
(Refer to Fig. 11)
Usage of oor brush
The oor brush can be used for cleaning
carpet and oor. Adjust the duty of the brush
by pressing the relative button. When the
oor nozzle extends out brush, it is for bare
oor, if without, for carpet. (Refer to Fig.12)
CAUTION:
The vacuum cleaner can suck both water and
dust. The vacuum cleaner won‘t run, when
the water in the barrel is full.
Usage of adjustable tube
Adjust the tube to a proper length by pushing
the control button; and the tube will be lock
automatically after releasing the button.
(Refer to Fig. 13)
DUST EMPTY AND MAINTENANCE
1. Release the buckle and remove the main
body and clapboard assembly. (Refer to
Fig. 14)
2. Pour out the sewage and rinse the barrel
under water. (Refer to Fig. 15)
CAUTION:
• Remove the hose assembly before
releasing the buckle assembly.
• The lter should be cleaned twice a year.
Or if it is visibly dusty, clean it at once.
• Never use this appliance without lter.
• Replace the lter once it is damaged.
• Never clean the lter with washing
machine.
3. Take out the sponges and cyclone-bulder
from the clapboard, and then rinse them
in water. (Refer to Fig. 16)
4. Take out the cyclone-bulder from the
clapboard assembly, and then rinse them
under water. (Refer to Fig. 17)
5. Take out the lter from the main body
Assembly, and then cleaning in water and
let dry naturaly. (Refer to Fig. 18)
