Nilfisk SR 1601 [77/132] Accessories options

USER MANUAL

ENGLISH

SR 1601 D3 / LPG3 / P3 33019216(3)2010-09 A

11

ACCESSORIES/OPTIONS

In addition to the standard components, the machine can be equipped with the following accessories/options, according to the

machine specifi c use:

Driver’s seat armrests –

Soft cabin –

Flashing light –

Working lights –

Headlights –

Rear bumper –

Hopper protection –

Side broom guard –

Overhead guard canopy –

Anti-skid mat –

Overhead guard –

Tilt steering wheel (equipped on SR 1601 MAXI) –

Hopper lower protection –

Driver’s seat plate –

For further information about the above-mentioned accessories, contact an authorised Retailer.

TECHNICAL DATA

Dimensions and weights SR 1601 D3 SR 1601 LPG3 SR 1601 P3

Cleaning path with main broom 35.5 in (900 mm)

Cleaning path with one side broom 49.25 in (1,250 mm)

Maximum hopper lifting height 62.5 in (1,590 mm)

Main broom size (diameter x length) 12.2 x 35.5 in (310 x 900 mm)

Side broom diameter 21.5 in (550 mm)

Tyre pressure 85 psi (6 Bar)

Maximum capacity 800 lb (365 kg)

Front axle kerb weight 1,180 lb (535 kg)

Rear axle kerb weight 905 lb (410 kg)

Total machine kerb weight (without operator) 2,085 lb (945 kg)

Maximum weight 2,885 lb (1,310 kg)

Machine weight for shipment 2,204.6 lb (1,000 kg)

For other engine data/values, see the Engine Manual.(*)

For engine oil and coolant data, and for technical specifi cations refer to the Engine Manual.(**)
