ESIE06-04 Field settings

Part 4 – Commissioning and Test Run 4–9

Procedure To change one or more field settings, proceed as follows:

1 Press the z button for a minimum of 5 seconds to enter FIELD SET MODE.

The $ icon (3) will be displayed. The current selected field setting code is indicated ;

(2), with the set value displayed to the right : (1).

2 Press the bgi button to select the appropriate field setting first code.

3 Press the bgj button to select the appropriate field setting second code.

4 Press the pfi button and pfj button to change the set value of the select field

setting.

5 Save the new value by pressing the pr button.

6 Repeat step 2 through 4 to change other field settings as required.

7 When finished, press the z button to exit FIELD SET MODE

Note Changes made to a specific field setting are only stored when the pr button is pressed. Navigating

to a new field setting code or pressing the z button will discard the change made.

Remarks P Before shipping, the set values have been set as shown under "Overview of the Field Settings by

Remote Control" on page 4–10.

P When exiting FIELD SET MODE, “88” may be displayed on the user interface LCD while the unit

initialises itself.
