ESIE06-04 Hydro-kit Functional Concept
Part 2 – Functional Description 2–9
3
2
4
5
1
2.3 Forced Operation Model
Outline Forced operating mode includes only forced cooling as pumpdown operation.
Detail Forced cooling
Item Forced cooling
Forced operation allowing
conditions
P The outdoor unit is not abnormal and not in the 3-minute
stand-by mode.
P The operating mode of the outdoor unit is the stop mode.
P The forced operation is ON.
The forced operation is allowed when the above “and”
conditions are met.
Starting/adjustment: If the forced operation switch is pressed as the above
conditions are met.
P Command frequency 55 Hz (cooling), 66 Hz (heating).
P Electronic expansion valve
opening
It depends on the capacity of the operating Hydro-kit.
P Outdoor unit adjustment Compressor is in operation.
P Hydro-kit adjustment The command of forced operation is transmitted to the
Hydro-kit.
End
P When the forced operation switch is pressed again.
P The operation is to end automatically after 15 min.
Others The protect functions are prior to all others in the forced
operation.
