ESIE06-04 Specifications
Part 1 – System Outline 1–11
3
1
4
5
Electrical
specifications
The table below contains the electrical specifications.
Specification EWAQ005AAV3P EWAQ006AAV3P EWAQ007AAV3P EWYQ005AAV3P EWYQ006AAV3P EWYQ007AAV3P
Power supply Name V3
Phase 1~
Frequency 50 Hz
Voltage 230 V
Voltage tolerance - min. 10 %
Voltage tolerance - max. 10 %
Unit Starting current - - - - - -
Zmax list No requirements
Zmax text -
Starting current soft start -
Zmax list -
Zmax text -
Nominal running current cooling - - - - - -
Nominal running current heating - - - - - -
Maximum running current 17.3 A 19 A
Recommended fuses according
to IEC standard 269-2
20
Fans Quantity 1
Phase 1~
Voltage 230 V
Nominal running current - - - - - -
Maximum running current - - - - - -
Starting current - DOL - - - - - -
Pump Phase 1~
Power input 0.13 kW
Speed 1050 / 2250 / 2450 rpm
Voltage 230 V
Maximum running current 0.58 A
Evaporator heater tape Supply voltage 230 V
Capacity 75 W
Voltage tolerance min. 10 %
Voltage tolerance max. 10 %
Recommended fuses (1) 20 A 20 A 20 A 25 A 25 A 25 A
NOTE (1) Fuse value valid for complete unit
